ATC SCM19 Passive Bookshelf Speakers | Black Ash
Super Linear Driver Engineering
The ATC SCM19 is the largest passive bookshelf loudspeaker in ATC’s Entry Series. It combines a 150mm SL bass and midrange driver, incorporating a substantial 75mm soft dome, with ATC’s 25mm soft dome tweeter in a curved cabinet. This listing is for the Black Ash veneer version.
Purpose Built for Music
The SCM19 uses a 9kg motor assembly with a short coil and long magnetic gap, together with a hand wound flat wire coil. Its high frequency unit includes a precision alloy waveguide, while the drivers are matched to within ±0.5dB. The emphasis is on controlled driver behaviour and consistent response across the listening area.
Partner with Quality Amplification
A passive design with an 8 ohm nominal impedance and a flat impedance curve, the SCM19 is designed to work with a separate power or integrated amplifier. ATC recommends amplification from 75 to 300 watts. Binding posts accept 4mm plugs and support biwiring.
KEY FEATURES:
- Black Ash veneer
- ATC 25mm soft dome tweeter with precision alloy waveguide
- ATC 150mm SL bass and midrange driver with 75mm integral soft dome
- Matched response: ±0.5dB
- Frequency response: 54Hz to 22kHz at minus 6dB
- Sensitivity: 85dB at 1W at 1 metre
- Maximum SPL: 108dB
- Recommended amplifier power: 75 to 300 watts
- Nominal impedance: 8 ohms
- Crossover frequency: 2.5kHz
- Binding posts for 4mm plugs with biwiring support
- Cabinet dimensions: 438 × 265 × 300mm (H × W × D); grille adds 34mm to depth
- Weight: 17.8kg per speaker
