ATC SCM7 Passive Bookshelf Speakers | Black Ash
Compact Cabinet, Dedicated ATC Drivers
The ATC SCM7 brings the company’s passive loudspeaker design into a compact bookshelf format. Its curved cabinet houses ATC drive units developed and built in house, combining a 25mm soft dome tweeter with a 125mm bass and midrange driver. This listing is for the Black Ash veneer version.
Purpose Built for Music
The SCM7 uses a hand wound ribbon wire voice coil and an optimised motor assembly. Its high frequency unit includes a precision alloy waveguide, while the drivers are matched to within ±0.5dB. The emphasis is on controlled driver behaviour and consistent response across the listening area.
Partner with Quality Amplification
A passive design with an 8 ohm nominal impedance and a flat impedance curve, the SCM7 is designed to work with a separate power or integrated amplifier. ATC recommends amplification from 75 to 300 watts. Binding posts accept 4mm plugs and support biwiring.
KEY FEATURES:
- Black Ash veneer
- ATC 25mm soft dome tweeter with precision alloy waveguide
- ATC 125mm SC bass and midrange driver with integral soft dome
- Matched response: ±0.5dB
- Frequency response: 60Hz to 22kHz at minus 6dB
- Sensitivity: 84dB at 1W at 1 metre
- Maximum SPL: 103dB
- Recommended amplifier power: 75 to 300 watts
- Nominal impedance: 8 ohms
- Crossover frequency: 2.5kHz
- Binding posts for 4mm plugs with biwiring support
- Cabinet dimensions: 300 × 174 × 215mm (H × W × D); grille adds 28mm to depth
- Weight: 7.5kg per speaker
